ATR46SS 1100HP ~ 1400HP Billet wheel externally gated Turbocharger

$2,500.00 – $2,800.00

This turbocharger is best working with 3~5L 6~8 cyc engines. Turbocharger is available in both ceramic ball bearings or journal bearings with 360 degrees thrust. This turbocharger must work with an fully operational blow off valve (BOV). The leading time to build is up to 1..
Clear

Additional Components (copy)

Product price
Additional options total:
Order total:
SKU: ATR46ss Categories: , Tags: , , , ,

Brand: HyperGear
Product Code: ATR46ss

This turbocharger is best working with 3~5L 6~8 cyc engines.

Turbocharger is available in ceramic ball bearings cored.

This turbocharger must work with an fully operational blow off valve (BOV).

The leading time to build is up to 15 working days.

Please check out our “Dyno results” tab for power figures and vehicle setups.

Current version release date: 25/07/2023

Warranty: 12 Month unlimited KM warranty comes with all of our turbochargers. Warranty voids if failure caused from Installation faults, Oil starvation, Operational, faults or object damages, We are not liable for the cost of many mechanical charges involved in fitting or removing of the product nor any shipping costs involved.

Weight 15 kg
Dimensions 400 × 400 × 400 cm

Dyno Results

Results:
Nissan Skyline
Rb25det head with forged Rb30det bottom
Forged pistons and con-rod
Upgraded Valve springs
HKS 256/ 264 drop in cams
1650cc Bosch fuel injectors
Two 460L fuel pumps
Haltech ECU
Hypergear ATR46SS-1Turbocharger in T3 .63 turbine
6 boost high mount TS exhaust manifold
Turbosmart 50mm external gates
516rwkws @ 26psi
569rwkws @ 29psi
606rwkws @ 30psi
642rwkws @ 34psi
Power:
Boost:
Toyota Chaser
Bult 2JZGTE None VVTi engine
264 Cam shafts
Upgraded Valve springs
High mount exhaust manifold
Haltech ECU
600x300x130mm custom built Cooler kit
4inches Turbo back exhaust
50mm external gate U
pgrade coil packs
HyperGear ATR46SS-1 Turbocharger in T4 1.01 turbine
2 Speed Auto
 Final result of 915rwhp / 683rwkws @ 34psi E85 fuel
Boost graph:
HyperGear ATR46SS-2 turbocharger Test and tune
Ford XR6 Turbo FG
Built 4L Barra engine
Built factory ZF 6 speed auto
Stock Cams with upgraded valve springs
HyperGear ATR46SS-1 Turbocharger
Turbosmart 60mm External Gate
4″ dump/front pipe
Front mount intercooler
Bosch 1650cc injectors
Twin walbro 460 pumps
Haltech ECU
Car built and tuned by All Sport Automotive

2019 model Audi RS3 with Forged engine
ATR46SS-2 Turbocharger in Vband-Vband .83 rear
Upgraded cams
Forged alloy intake
Upsized fuel system
PWR front mount cooler kit
3.5 inches exhaust
WMI kit 50/50 Mix
Final result of 828awkws E85 fuel on Mainline roller dyno
Car run 8.92 Sec 1/4 mile.
