ATR46 T4 1000HP Externally gated Turbocharger

$1,200.00

This turbocharger is best working with 4~5L 6~8 cyc engines. Turbine A/R: 1.26, Wheel turbine wheel dia: 82mm Comp A/R: 0.75, Comp wheel dia: 102mm This turbocharger must work with an fully operational blow off valve (BOV). The leading time to build is up to 15 working days. ..

Availability: 10 in stock

Product price
Additional options total:
Order total:
SKU: ATR46 Categories: , Tags: , , ,

Brand: HyperGear
Product Code: ATR46

This turbocharger is best working with 4~5.7L, 6~8 cyc engines.

Turbine A/R: 1.26, Wheel turbine wheel dia: 82mm
Comp A/R: 0.75, Comp wheel dia: 102mm

Power rating: upto 1000bhp

This turbocharger must work with an fully operational blow off valve (BOV).

The leading time to build is up to 15 working days.

Current version release date: 09/09/2016

Warranty: 12 Month unlimited KM warranty comes with all of our turbochargers. Warranty voids if failure caused from Installation faults, Oil starvation, Operational, faults or object damages, We are not liable for the cost of many mechanical charges involved in fitting or removing of the product nor any shipping costs involved.

Weight 9 kg
Dimensions 20 × 20 × 20 cm

Specification

Turbochargers
Car 3.0L +
Engine 3.0L +
Profile Profile G1: 900HP
Max Out put: 900 HP
Compressor Wheel Inducer: 75 mm
Exducer: 102 mm
Turbine Wheel Inducer: 82 mm
Trim:84
Manifold flange: T6x
A/R: 1.26
Cooling Method Oil
Key Benefits Stainless steel thrust bearing system
Heat treated steel wheel and shaft
Suitable for High Boost applicationsHigh torque, High Power
Long life time.
Made for all 3L+ High performance
Turbo charging applications.
Item Includes Turbocharger Itself Only
Warranty Our turbochargers comes with 12 month unlimited KMs warranty on all components
supplied. This warranty does not cover failures cased from foreign objects or oil related issues.

Dyno Results

Dyno result:
Ford XR6T FG 4L Barra Auto
Atomic Valve springs
ID 1200cc injectors
Factory ECU Remap
Greedy Profect B EBC
600x300x100mm  Cooler kit
3.5inches Turbo back exhaust
High mount exhaust mount manifold
50mm external gate
510rwkws @ 24psi E85 Fuel
